HPT 4500 TG








HOSTAR Model HPT4500 TG Tri-Axle Hydraulic Boat Trailer for ramp use, configured with the following equipment and/or specifications:

• To handle power boats and shoal draft sailboats to 45 feet
• Trailer length overall: 46 to 52 feet (as desired)
• Trailer width overall: 9 feet (or wider/narrower as necessary)
• Gooseneck length: 8 to 10 feet (to fit truck dimensions)
• Capacity of 32,000 lbs. over the road, 38,000 lbs. in the yard
• 10" x 10" x 3/8" structural steel tube main frame
• Hydraulics:
    * Two offset rear hydraulic arms with extendable pads
    * Forward hydraulic arms, manually extendable
    * Manual hydraulic control valves
    * 12VDC electric hydraulic power unit
    * Pilot operated double-locking valves on all cylinders
• Three Dexter Heavy Duty Series 12,000 lb. axles
• Six 235/75R 17.5, 16 ply, Load Range H radial tires
• Six-wheel air-ride suspension, dual manual controls
• Field-replaceable reinforced fiberglass suspension bushings
• Air/hydraulic drum brakes on all wheels
• Two movable, adjustable and reversible forward cross beams
• Two-position ratchet adjustable swing-out rear cross beam
• Flexible fenders
• Two screw pad stabilizers with sockets and T-pins, mountable to frame
• Stainless steel T-pins and hardware
• Extra-bright LED submersible lighting system
• Expanded metal basket at trailer front
• Two parking stands
• Finish: Entire frame sandblasted to white steel, finished with two coats high-build epoxy primer with hardener,
             three coats high performance acrylic urethane with hardener - choice of color

Production Time: Fourteen to sixteen weeks from start of construction



Available Options


• Galvanized arms, arm inserts, pad brackets, parking stands only
• 12VDC air compressor with cover, mounted in gooseneck
• Remote control with pendant operation, priced per hydraulic function
• Remote control with pendant operation, priced per air function
• Wireless remote control in lieu of pendant operation
• Corrosion-resistant disc brake package
• Full air brakes
• Extra bright LED submersible lighting system
• 12.5K electric planetary gear winch, mounted on gooseneck
• Frame extended, priced per foot
• Spare tire and wheel
• Hydraulically articulating (in lieu of fixed) gooseneck
• Two telescoping drop beams for sailboat keels
• Hydraulic landing wheels (each side of gooseneck)
• Pneumatic lift on front axle
